Application Scenarios：
Ship station, Stock-breeding, Data center, Industrial park, Household
| Parameter | Specification |
| Model | 125kW/500kWh |
| Rated Voltage | 480VDC |
| Rated Current | 105A |
| Rated Energy Efficiency | >70% |
| Maximum Current | 125A |
| Rated Power | 150kW |
| Rated Duration* | 4h |
| Rated Energy* | 500kWh (Included) |
| Rated Capacity | 420Ah |
| Battery Weight | 45T |
| Energy Storage Cabinet Size | 12.2*2.45*2.9m |
| Electrolyte Weight | 14T |
| Electrolyte Volume | 25m³ |
| Electrolyte Concentration | 1.7M V (IV/III) |
| Operating Temperature Range | 0~40°C |
| Charging Limit Voltage | 600VDC |
| Discharge Limit Voltage | 400VDC |
| Cycle Life | 20,000 cycles |
| Storage Life | Unlimited |
| Protection Level | IP54 |
| AC Rated Voltage | 220V/380V |
Application scenarios
Factory electricity
It is important to choose a safe energy storage battery
Supports multiple charges and discharges, with a maximum battery life of 14 hours
Can be matched in many ways
Vanadium battery-assisted diesel generator to generate electricity
Vanadium battery-assisted gas turbine power generation
Vanadium batteries used for frequency regulation in power plants
In the era of new energy power generation, vanadium batteries replacing traditional transformers will reduce the pressure on the power grid.
Vanadium batteries are also suitable for a variety of scenarios, such as power protection for water pumps in seawater desalination equipment, domestic power consumption on large freighters, operation in high-altitude areas below 3,000 meters above sea level, and in cold, hot and humid areas.
Application Scenarios：
Ship station, Stock-breeding, Data center, Industrial park, Household
| Parameter | Specification |
| Model | 125kW/500kWh |
| Rated Voltage | 480VDC |
| Rated Current | 105A |
| Rated Energy Efficiency | >70% |
| Maximum Current | 125A |
| Rated Power | 150kW |
| Rated Duration* | 4h |
| Rated Energy* | 500kWh (Included) |
| Rated Capacity | 420Ah |
| Battery Weight | 45T |
| Energy Storage Cabinet Size | 12.2*2.45*2.9m |
| Electrolyte Weight | 14T |
| Electrolyte Volume | 25m³ |
| Electrolyte Concentration | 1.7M V (IV/III) |
| Operating Temperature Range | 0~40°C |
| Charging Limit Voltage | 600VDC |
| Discharge Limit Voltage | 400VDC |
| Cycle Life | 20,000 cycles |
| Storage Life | Unlimited |
| Protection Level | IP54 |
| AC Rated Voltage | 220V/380V |
Application scenarios
Factory electricity
It is important to choose a safe energy storage battery
Supports multiple charges and discharges, with a maximum battery life of 14 hours
Can be matched in many ways
Vanadium battery-assisted diesel generator to generate electricity
Vanadium battery-assisted gas turbine power generation
Vanadium batteries used for frequency regulation in power plants
In the era of new energy power generation, vanadium batteries replacing traditional transformers will reduce the pressure on the power grid.
Vanadium batteries are also suitable for a variety of scenarios, such as power protection for water pumps in seawater desalination equipment, domestic power consumption on large freighters, operation in high-altitude areas below 3,000 meters above sea level, and in cold, hot and humid areas.
SINJI mainly sells vanadium battery system, reactor, vanadium electrolyte and perfluoride ion membrane.
